Tellure Rôta · Rubber

Series 72AL

Sigma Elastic rubber wheels, aluminium centre

Articles: 101
Diameters: Ø100–250 mm
Maximum load: 1,000 daN
Tread: Elastic rubber

View the 101 articles in the finder Request a quote

Rubber

Series 72AL

Articles in this series

Every code in the series, grouped by wheel and bracket type. Select a code to see its datasheet, drawing and quote.

Ruedas en goma "Sigma Elastic", núcleo en aluminio20 articles · Ø100–250 mm

Code	Size	Load (daN)	Bearing	Brake
721202	Ø100×40 mm	180	Ball bearings	No
723102	Ø100×40 mm	180	Bearing housing	No
721103	Ø125×40 mm	200	Ball bearings	No
721203	Ø125×40 mm	200	Ball bearings	No
723003	Ø125×40 mm	200	Bearing housing	No
723103	Ø125×40 mm	200	Bearing housing	No
721213	Ø125×50 mm	230	Ball bearings	No
723113	Ø125×50 mm	230	Bearing housing	No
721110	Ø160×50 mm	300	Ball bearings	No
721210	Ø160×50 mm	300	Ball bearings	No
723104	Ø160×50 mm	300	Bearing housing	No
721205	Ø180×50 mm	350	Ball bearings	No
723105	Ø180×50 mm	350	Bearing housing	No
721106	Ø200×50 mm	500	Ball bearings	No
721206	Ø200×50 mm	500	Ball bearings	No
721306	Ø200×50 mm	500	Ball bearings	No
723106	Ø200×50 mm	500	Bearing housing	No
723126	Ø200×50 mm	500	Bearing housing	No
721208	Ø250×50 mm	500	Ball bearings	No
723108	Ø250×50 mm	500	Bearing housing	No

Ruedas en goma "Sigma Elastic", núcleo en aluminio, soporte giratorio pletina P6 articles · Ø100–250 mm

Code	Size	Load (daN)	Bearing	Brake
727602	Ø100×40 mm	180	Ball bearings	No
727613	Ø125×50 mm	230	Ball bearings	No
727610	Ø160×50 mm	300	Ball bearings	No
727605	Ø180×50 mm	350	Ball bearings	No
727516	Ø200×50 mm	500	Ball bearings	No
727518	Ø250×50 mm	500	Ball bearings	No

Ruedas en goma "Sigma Elastic", núcleo en aluminio, soporte giratorio pletina NL5 articles · Ø100–200 mm

Code	Size	Load (daN)	Bearing	Brake
724402	Ø100×40 mm	180	Ball bearings	No
724413	Ø125×50 mm	230	Ball bearings	No
724410	Ø160×50 mm	300	Ball bearings	No
724405	Ø180×50 mm	300	Ball bearings	No
724306	Ø200×50 mm	300	Ball bearings	No

Ruedas en goma "Sigma Elastic", núcleo en aluminio, soporte giratorio pletina P con freno registrable5 articles · Ø125–250 mm

Code	Size	Load (daN)	Bearing	Brake
727213	Ø125×50 mm	230	Ball bearings	Yes
727204	Ø160×50 mm	300	Ball bearings	Yes
727205	Ø180×50 mm	350	Ball bearings	Yes
727206	Ø200×50 mm	500	Ball bearings	Yes
727208	Ø250×50 mm	500	Ball bearings	Yes

Ruedas en goma "Sigma Elastic", núcleo en aluminio, soporte giratorio pletina NL freno delantero5 articles · Ø100–200 mm

Code	Size	Load (daN)	Bearing	Brake
727302	Ø100×40 mm	180	Ball bearings	Yes
727313	Ø125×50 mm	230	Ball bearings	Yes
727310	Ø160×50 mm	300	Ball bearings	Yes
727305	Ø180×50 mm	300	Ball bearings	Yes
727106	Ø200×50 mm	300	Ball bearings	Yes

Ruedas de goma Sigma Elastic, núcleo de aluminio, soporte giratorio EE MHD5 articles · Ø125–250 mm

Code	Size	Load (daN)	Bearing	Brake
728303	Ø125×50 mm	230	Ball bearings	No
728314	Ø160×50 mm	300	Ball bearings	No
728305	Ø180×50 mm	350	Ball bearings	No
728306	Ø200×50 mm	500	Ball bearings	No
728307	Ø250×50 mm	500	Ball bearings	No

Ruedas de goma Sigma Elastic, núcleo de aluminio, soporte giratorio EE MHD, freno trasero regulable5 articles · Ø125–250 mm

Code	Size	Load (daN)	Bearing	Brake
728603	Ø125×50 mm	230	Ball bearings	Yes
728614	Ø160×50 mm	300	Ball bearings	Yes
728605	Ø180×50 mm	350	Ball bearings	Yes
728606	Ø200×50 mm	500	Ball bearings	Yes
728607	Ø250×50 mm	500	Ball bearings	Yes

Ruedas en goma "Sigma Elastic", núcleo en aluminio, soporte giratorio pletina PT4 articles · Ø125–200 mm

Code	Size	Load (daN)	Bearing	Brake
725503	Ø125×50 mm	230	Ball bearings	No
725510	Ø160×50 mm	300	Ball bearings	No
725505	Ø180×50 mm	350	Ball bearings	No
725516	Ø200×50 mm	500	Ball bearings	No

Ruedas en goma "Sigma Elastic", núcleo en aluminio, soporte giratorio pletina PT con freno registrable4 articles · Ø125–200 mm

Code	Size	Load (daN)	Bearing	Brake
728203	Ø125×50 mm	230	Ball bearings	Yes
728204	Ø160×50 mm	300	Ball bearings	Yes
728205	Ø180×50 mm	350	Ball bearings	Yes
728206	Ø200×50 mm	500	Ball bearings	Yes

Ruedas en goma "Sigma Elastic", núcleo de aluminio, soporte giratorio pletina NL con centralizado registrable de doble posición3 articles · Ø125–200 mm

Code	Size	Load (daN)	Bearing	Brake
724703	Ø125×40 mm	230	Ball bearings	Yes
724710	Ø160×50 mm	300	Ball bearings	Yes
724706	Ø200×50 mm	300	Ball bearings	Yes

Ruedas en goma "Sigma Elastic" núcleo de aluminio, soporte giratorio con amortiguación a pletina EES MHD3 articles · Ø160–250 mm

Code	Size	Load (daN)	Bearing	Brake
726304	Ø160×50 mm	300	Ball bearings	No
726306	Ø200×50 mm	500	Ball bearings	No
726308	Ø250×50 mm	500	Ball bearings	No

Ruedas en goma "Sigma Elastic", núcleo de aluminio, soporte giratorio con amortiguación a pletina EES MHD con freio3 articles · Ø160–250 mm

Code	Size	Load (daN)	Bearing	Brake
726504	Ø160×50 mm	300	Ball bearings	Yes
726506	Ø200×50 mm	500	Ball bearings	Yes
726508	Ø250×50 mm	500	Ball bearings	Yes

Ruedas en goma "Sigma Elastic", núcleo en aluminio, soporte giratorio pletina M2 articles · Ø160–200 mm

Code	Size	Load (daN)	Bearing	Brake
724610	Ø160×50 mm	300	Ball bearings	No
724506	Ø200×50 mm	500	Ball bearings	No

Ruedas en goma "Sigma Elastic", núcleo en hierro fundido mecánico, soporte giratorio pletina M freno delantero2 articles · Ø160–200 mm

Code	Size	Load (daN)	Bearing	Brake
727910	Ø160×50 mm	300	Ball bearings	Yes
727706	Ø200×50 mm	500	Ball bearings	Yes

Ruedas en goma "Sigma Elastic", núcleo en aluminio, soporte giratorio pletina EEG MHD2 articles · Ø100–125 mm

Code	Size	Load (daN)	Bearing	Brake
728062	Ø100 mm	360	Ball bearings	No
728063	Ø125 mm	400	Ball bearings	No

Ruedas en goma "Sigma Elastic", núcleo en aluminio, soporte giratorio pletina EEG HD2 articles · Ø160–200 mm

Code	Size	Load (daN)	Bearing	Brake
728084	Ø160 mm	600	Ball bearings	No
728086	Ø200 mm	1,000	Ball bearings	No

Ruedas en goma 'Sigma Elastic', núcleo en aluminio, soporte giratorio pletina EEG HD, freno trasero2 articles · Ø160–200 mm

Code	Size	Load (daN)	Bearing	Brake
728784	Ø160 mm	600	Ball bearings	Yes
728786	Ø200 mm	1,000	Ball bearings	Yes

Ruedas en goma "Sigma Elastic", núcleo en aluminio, soporte fijo P6 articles · Ø100–250 mm

Code	Size	Load (daN)	Bearing	Brake
728512	Ø100×40 mm	180	Ball bearings	No
728523	Ø125×50 mm	230	Ball bearings	No
728514	Ø160×50 mm	300	Ball bearings	No
728515	Ø180×50 mm	350	Ball bearings	No
728516	Ø200×50 mm	500	Ball bearings	No
728518	Ø250×50 mm	500	Ball bearings	No

Ruedas en goma "Sigma Elastic", núcleo en aluminio, soporte fijo NL-M5 articles · Ø100–200 mm

Code	Size	Load (daN)	Bearing	Brake
726202	Ø100×40 mm	180	Ball bearings	No
726213	Ø125×50 mm	230	Ball bearings	No
726210	Ø160×50 mm	300	Ball bearings	No
726205	Ø180×50 mm	350	Ball bearings	No
725206	Ø200×50 mm	500	Ball bearings	No

Ruedas de goma Sigma Elastic, núcleo de aluminio, soporte fijo EE MHD5 articles · Ø125–250 mm

Code	Size	Load (daN)	Bearing	Brake
728403	Ø125×50 mm	230	Ball bearings	No
728414	Ø160×50 mm	300	Ball bearings	No
728405	Ø180×50 mm	350	Ball bearings	No
728406	Ø200×50 mm	500	Ball bearings	No
728407	Ø250×50 mm	500	Ball bearings	No

Ruedas en goma "Sigma Elastic", núcleo de aluminio, soporte fijo con amortiguación EES MHD3 articles · Ø160–250 mm

Code	Size	Load (daN)	Bearing	Brake
726404	Ø160×50 mm	300	Ball bearings	No
726406	Ø200×50 mm	500	Ball bearings	No
726408	Ø250×50 mm	500	Ball bearings	No

Ruedas de goma Sigma Elastic, núcleo de aluminio, soporte fijo EEG MHD2 articles · Ø100–125 mm

Code	Size	Load (daN)	Bearing	Brake
728162	Ø100 mm	360	Ball bearings	No
728163	Ø125 mm	400	Ball bearings	No

Ruedas de goma Sigma Elastic, núcleo de aluminio, soporte fijo EEG HD2 articles · Ø160–200 mm

Code	Size	Load (daN)	Bearing	Brake
728184	Ø160 mm	600	Ball bearings	No
728186	Ø200 mm	1,000	Ball bearings	No

View the 101 articles in the finder
